Technical parameters:

Lamp: 1200 w short arc gas discharge bubble

Cap: GY - 22

Available type: PHILIPS HMI1200

Rectifier: electromagnetic ballast

Power supply: 208/230/250 v, fifty hz, 208/230 v, sixty hz

Power: 1500 w, 220 v/fifty hz

The biggest environmental temperature: ℃ (104 ° F)

Maximum surface temperature; 135 ℃ (275 ° F)

Size: 619 x536x616 (mm)

Net weight: kg

Gross weight: 83 kg

Performance characteristics

Communication protocol: DMX - 512

Control channel: and ch

Display: LCD graphics display

Horizontal/vertical accuracy: 8 or 16 bit

Design positioning: 8 or 16 bit

Prism location: 8 or 16 bit

Mobile control: tracking and vector

Data input/output: 3 core

Green: 0-100% magenta: 0-100%

Huang: 0-100% CTO: 0-100%

The color wheel: six can change color + white light

Pattern wheel for a replaceable glass design + white light

Pattern wheel but a replaceable glass design + white light

Pattern sheet size: 37 mm

Aperture: motor, linear

Effect of wheel: 4 replaceable prism and effect + white light

Atomization effect: independence, adjustable

Adjustable light/stroboscopic: linear dimming and adjustable speed frequency flash
